Basic information
| Standard | DIN |
| Connection type | clamp DN40 - CLAMP collar 50.5 mm |
| Control: pneumatic drive (air pressure P_pilot | 5–8 bar) |
| Pressure P_max (stainless steel valve body) | 16 bar |
| Material | stainless steel 1.4404 (AISI 316L) |
| Max. working temperature | –10 °C to 100 °C |
| Sanitation temperature | 150 °C (max. 20 min) |
| Seal | PTFE |
| Diaphragm | VMQ (silicone) or EPDM (customer's choice - best to consult with our technician) |
| The material of the pneumatic head | plastic |
Dimension - see the dimensioned picture
| Length (mm) | 163 |
| Height including the pneumatic drive (mm) | 226 |
| The inner diameter of the stainless steel pipe (mm) | 35 |
| The outer diameter of the stainless steel pipe (mm) | 39 |
| Clamp collar (mm) | 50.5 |
Fields of application of pneumatically operated diaphragm valve
Winery, brewing, dairy, beverage, food production, pharmacy, etc.
