Basic information
| Standard | DIN |
| Type | clamp connection, DN20 - CLAMP 34mm |
| Working pressure | 0–8 bar |
| Material | stainless steel 1.4404 (AISI 316L) |
| Maximal working temperature | –10 °C to 100 °C |
| Sterilization temperature | 150 °C (max. 20min) |
| Gasket | PTFE |
| Diaphragm | VMQ (silicone) or EPDM |
| Control | pneumatical actuator ( air pressure 5–8 bar) |
| Material pneumatical head | plastic |
Dimensions
| Length(mm) | 122 |
| Height including pneumatic actuator (mm) | 210 |
| The inner diameter of a stainless tube (mm) | 20 |
| The outer diameter of a stainless tube(mm) | 23 |
| Clamp collar (mm) | 34 |
Application areas of diaphragm valve
Wineries, breweries, dairy industry, beverage industry, food production, is widely used in pharmacy, etc.
