Basic information
| Standard | DIN |
| Connection type | clamp DN32 - CLAMP collar 50.5 mm |
| Control: pneumatic drive (air pressure P_pilot | 5–8 bar) |
| Pressure P_max (stainless steel body of valve) | 16 bar |
| Material | stainless steel 1.4404 (AISI 316L) |
| Max. working temperature | –10 °C to 100 °C |
| Sterilization temperature | 150 °C (max. 20 min) |
| Gasket/Seal | PTFE |
| Diaphragm | VMQ (silicone) or EPDM (according to customer's choice - best consult with our technician) |
| Pneumatic head material | plastic |
Dimensions - see dimensioned image
| Length (mm) | 152 |
| Height including the pneumatic drive (mm) | 226 |
| The inner diameter of the stainless steel tube (mm) | 30 |
| The outer diameter of the stainless steel tube (mm) | 34 |
| Clamp collar (mm) | 50.5 |
Fields of application of pneumatically operated diaphragm valve
Winery, brewing, dairy, beverage, food production, pharmacy, etc.
