Basic information
These dampers are designed to be mounted on stainless steel pipes and their purpose is to prevent backflow of liquid. In order to guarantee its functionality, it is necessary to ensure a constant flow of medium without sudden fluctuations. They are not suitable for media with solid particles.
Properties
- Material: stainless steel DIN 1.4408 (CF8M-standard ASTM A352)
- Connection: inner thread BSP-G 1"
- Maximal working pressure: 13 bar (200PSI)
- Maximal working temperatures: –10 °C/160 °C
- Designed for: liquid, water, oil
- Without gasket
Most common areas of check valves applications
Wineries, breweries, dairy industry, beverage industry, food processing, pharmaceuticals etc.
