Basic information
| Type | threaded G 1"- BSP |
| Pressure | 1.5 to 2.5 bar |
| Maximal working temperature | 95 °C |
| Maximal surrounding temperature | 140 °C |
| Radius of cleaning | 1.0 – 1.25 m |
| Size of holes | 2.5 mm |
| Flow | 17 m3/h (280 l/min) |
| Angle of cleaning | 360° |
| Material | stainless steel 1.4301 (AISI 304) |
| Diameter of ball | 63 mm |
| Whole high | 86 mm |
Application areas
Wineries, breweries, dairy industry, beverage industry, food production, is widely used in pharmacy etc.
