Basic information
| Standard | DIN |
| Connection | welded, DN100 |
| Material | stainless steel 1.4301 (AISI 304), borosilicate glass |
| Material of gasket | silikone |
| Working pressure | max. 6 bar |
| Max. working temperarute | 100 °C |
| Sanitary temperature | 120 °C |
| Medium | liquid |
Diameters
| ID | 100 mm |
| OD | 104 mm |
Montáž potrubního průhledítka
V případě přivařování je nutné armaturu nejdříve rozebrat, aby nedošlo k poškození těsnění. Doporučujeme kontrolu dotažení svorníků v provozu.
Application areas of sight glasses
Wineries, breweries, dairy industry, beverage industry, food production, is widely used in pharmacy etc.
Compatible accessories
Gasket Silicone For Straight Sight Glass, Type B…
Spare Gasket Silicone For Straight Sight Glass, Type B| DN100
Spare glass SIMAX for straight sight glass 115 mm…
Spare borosilicate glass SIMAX for straight sight glass| 115 mm/5 mm Diameters: height:…
