Basic information
| Standard | DIN |
| Connection type | clamp DN50 - CLAMP collar 64 mm |
| Control: pneumatic drive (air pressure P_pilot | 5–8 bar) |
| Pressure P_max (stainless steel valve body) | 16 bar |
| Material | stainless steel 1.4404 (AISI 316L) |
| Max. working temperature | –10 °C to 100 °C |
| Sanitation temperature | 150 °C (max. 20 min) |
| Seal | PTFE |
| Diaphragm | VMQ (silicone) or EPDM (customer's choice - best to consult with our technician) |
| Material of pneumatic head | plastic |
Dimensions
| Length (mm) | 195 |
| Length including the pneumatic drive (mm) | 276 |
| The inner diameter of the stainless steel pipe (mm) | 48 |
| The outer diameter of the stainless steel pipe (mm) | 52 |
| Clamp collar (mm) | 64 |
Fields of application of pneumatically operated diaphragm valve
Winery, brewing, dairy, beverage, food production, pharmacy, etc.
