Basic information
| Filtration material | Activated Carbon (min. 95% active chlorine removal efficiency) |
| Filtration ability | 5 µm (99% particle retention efficiency 10 µm)) |
| Length | 10“ (250 mm) |
| Seal/O-ring | NBR |
| Inner diameter | 1.1“ (28 mm) |
| Outer diameter | 4.5“ (115 mm) |
Operational data
| Max. working temperature | 80°C |
| Max. differential pressure | 6.9 bar at 25°C |
| Recommended replacement for pressure loss | 2.1 bar |
Differential pressure measurement is most often performed by pressure gauges before and after the filter and after reaching the limit pressure it is necessary to replace the filter elements.
| Flow | 0~4.5 m3/h |
Main application fields
Household water filtration, wastewater treatment, drinking water, RO / desalination pretreatment, beverage industry, food industry, electrical industry, chemical industry, cooling water, swimming pools, laboratories.
