Basic information
| Material | stainless steel, polyetheretherketone |
| Seal | NBR |
| Type | 2/2 without voltage closed(NC) |
| Valve type | directly controlled |
| Thread connection | G 1/2" |
| Working temperature | –10 °C to 50 °C |
| Medium temperature | –10 °C to 80 °C |
| Hole (Orifice) | 10 mm |
| Working pressure | 0.02 to 1.0 MPa (0.2–10 bar) |
| Flow rate | 1.4 m3/h |
| Voltage | 24 V DC |
| Power consumption | 15W |
The valves are supplied with coils and connectors.
